Embedded Display Terminal: Industrial-Grade Core Defying Extreme Environments
The body adopts a magnesium-aluminum alloy frame and nano-oil-repellent coating - even when corrosive liquids splash onto chemical plant self-inspection terminals, they wipe clean without leaving traces. Internally, it employs field-grade wide-voltage power supply (12-36V DC) with instant surge protection up to 4KV, ensuring highway toll machines operate stably during thunderstorms.
The fanless cooling architecture utilizes 96 honeycomb vents on the back to create air circulation, maintaining motherboard temperature below the 50℃ threshold inside outdoor charging cabinets at 55℃ ambient temperature, tripling the lifespan compared to consumer-grade screens.
Embedded Display Terminal: Precision Touch Enabling Complex Interactions
Addressing different touch requirements across scenarios, the terminal supports three freely switchable modes:
Medical scenarios: Latex glove operation mode reduces touch pressure threshold by 30%
Heavy industry scenarios: Anti-mis-touch mode requires double-click activation
Outdoor scenarios: Rain/fog mode automatically increases touch point recognition area
For instance, workers at steel mill self-service safety training machines can smoothly complete test questions while wearing thick gloves; community fresh food lockers automatically switch to anti-mis-touch logic during rain to prevent accidental payments triggered by water droplets.
Flexible Interfaces Driving Ecosystem Connectivity
The back panel reserves 6 expansion slots for modular integration of:
Financial-grade security: Fingerprint modules/ID card readers (hospital self-service terminals)
IoT sensing: Temperature/humidity sensors (medicine vending machines)
Payment connectivity: QR code scanners + facial payment modules (smart restaurant pickup lockers)
Through Type-C + RS485 dual-protocol interfaces, data integration with PLC and MES systems can be completed in just 5 minutes, upgrading standalone kiosks into interactive nodes of the Industrial IoT.
| 43-Inch Capacitive Touch System All-in-One Android Computer |
| LCD Panel Parameters |
Screen Size |
43 Inch |
| Display Area |
941.2 mm.(Height) X 529.4(Width)mm. |
| Aspect Ratio |
16 : 9 |
16 : 9 |
| LCD Type |
a-Si TFT-LCD Monitor |
a-Si TFT-LCD Monitor |
| Maximum Resolution |
1920 X 1080 |
3840 X 2160 |
| Display Color |
16.7m , 72% NTSC |
1.06B, 74% NTSC |
| Brightness |
300cd/m² |
400cd/m² |
| Contrast Ratio |
1200 : 1 |
1000 :1 |
| Viewing Angle (Up/Down/Left/Right) |
89°/89°/89°/89° (Type)(CR≥10) |
89°/89°/89°/89°(Type)(CR≥10) |
| Response Time |
8ms |
6ms |
